NOYITO Voltage to Current module, 0-2.5V ,0-3.3V,0-5V,0-10V,0-15V,0-24V voltage signal conversion to 0-20mA or 4-20mA current signal output, by adjusting the voltage to adjust the size of the current.Output Capacity: DC 4V - 60V, continuous current 10A, room temperature, power 600W! The current can reach 15A under auxiliary cooling conditions.ĭimensions: 0.47 x 1.34 x 0.67 Inches | Weight: 0.03 Pounds.

Low-level trigger voltage range: DC 0V-0.6V, trigger signal at 0V-0.6V, MOS transistor is on above 3.0V, MOS transistor is off signal voltage cannot be 0.6V-3.0V, because MOS tube is not complete Open circuit, high power output will damage MOS.The signal voltage cannot be 0.6V-3.0V, because the MOS tube is not fully open, the high power output will damage the MOS High-level trigger voltage range: DC3.0V-24V, trigger signal is 3.0V-24V, MOS tube is on less than 0.6V, ie 0V-0.6V, MOS tube is off.(Please refer to the second picture on the left for the wiring diagram) Working voltage input: DC 4V-60V Easy to control high power equipment.The module supports high level trigger, low level trigger, switch control, PWM control dual MOS parallel active output, low internal resistance, strong current, strong power, continuous current at room temperature is 10A, 600W, satisfying most Equipment.

The output frequency range grade is optional, making the output frequency more continuously adjustable low frequency range: 1Hz-50Hz, medium frequency range: 50Hz-1kHz, medium-high frequency range: 1KHz-10kHz, high frequency range: 10kHz-200kHz.

Output with LED indication, there is no output, visually visible (low LED when the high when the high level LED off when the frequency is relatively low, the LED flashes).

(Depending on the input voltage, the output amplitude will be different) The maximum output current: 15MA (5V power supply, V-PP greater than 50%), 35MA ( 12V power supply, when V-PP is greater than 50%)

Output amplitude: 4.2V V PP to 11.4V V-PP.

5V power supply, the output current can be around 15MA 12V power supply, the output current can be around 35MA input current: 100MA

The main chip: NE555 input voltage: 5V-15VDC.

Generate adjustable pulses to control the associated circuitry. Used to generate a square wave signal that drives a stepper motor driver.

The scope of application of this module: As a square wave signal generator, generate square wave signals for experimental development and use.

Wide application: this motor control module can tolerate wide input Voltage (DC 5-36v) it can be applied in various high power equipments, such as motors, light bulbs, LED lights, DC motors, micro-pumps, solenoid Valve can input PWM to control motor speed or Lamp Brightness.ĭimensions: 0.39 x 1.34 x 0.67 Inches | Weight: 10.00 Grams.

Perfect support PWM signal: the PWM controller can access PWM signal, which can perfectly supported the frequency of 0-20khz.
